1. Set dampproof, dustproof, loss prevention is equal to one;temperature and humidity relatively stable, ensure insulating tools usedmore security; computer control, NC compatible
2, the display cabinet for each test cycle of safety equipment, due to the automatic alarm. Show the number and wire grounding wire used in number, grounding out in the cabinet open recognition system, automatic monitoring of ground use. The grounding wire reset automatically close the display window, recovery apparatus test cycle countdown state.
3, appearance, appearance, characteristics of intelligent power tool cabinet:
(1) the cabinet body material for cold rolled steel sheet, roll welding molding, plate thickness of 1mm, body weight 75 kg to ensure bearing strength and standing stability.
(2) cabinet put oneself in another's position on the surface electrostatic spray the rot process, the color is camel gray wrinkled and doors with transparent organic glass, through the glass door can see the orderly classification of various instruments.
(3) cabinet appearance specifications: height * width * thick 2000*800*450 (mm), and mobile and flexible, easy to display, cabinet space can add infrared heat removal dehumidifier.
(4) the cabinet body structure can according to the customer demand according to different kinds of specifications and quantity of the space, the classification design and to implement tailored, classification and orderly, neat storage.
(5) outstanding dehumidifying capacity, stable operation, low noise, wet small rise, low failure rate, basically can be realized without maintenance or less maintenance, can adapt to the quick and repeated use of, timely to insulating tools for dehumidifying and drying treatment.
(6) control of accurate measurement, wide measurement range, can realize the observation in the cabinet and the dynamic synchronous display of the temperature and humidity data
(7) is simple and reliable to operate, free switch between automatic and manual control, in the automatic mode can be run according to preset parameters, and can automatically adjust according to changes in the external environment temperature of the temperature upper limit in the cabinet, to ensure that the cabinet tool used when no dew.
(8) there is a separate overtemperature protection device, can control the temperature in the cabinet does not exceed the maximum of 42 DEG C to ensure cabinet memory safety appliance not because of long-term high temperature so as to damage the other insulation performance, and to ensure the long-term and reliable and practical.
(9) the unique cabinet air circulation duct strong convection, creating a rapid equilibrium temperature of the internal environment
(10) with perfect safety protection measures, reliable grounding, cabinet is provided with a leakage protection device, power input end of the cabinet body and the insulating strength is more than or equal to 20m ohm, AC withstand voltage 2000V/2min, ensure the personal safety of users.
The product function and characteristics:
1, provide a suitable insulation tool storage environment, to keep it dry, accord with national standard insulation tool storage environment (GB/T18037) requirements.
2, can be stored at the same time, the insulating rod, an electroscope, a grounding wire, insulated gloves, insulated boots, belts, gas masks, the insulating rope, insulating baffle plate, a shielding clothing and other supplies, do comprehensive utilization.
3, according to the different place need to choose different internal structure, assembling, suitable place; according to different dimensions of the insulating teeth, choose products of different specifications, to meet the needs of the place.
4, remove the cases with no tools has the function of condensation.
5, to lower energy consumption, economic applicable in a timely manner to insulation tools to meet the needs of rapid drying treatment, repeated use.
6, the product adopt scientific adjustment algorithm, and the temperature and humidity independent control limit line, can carry out alarm, automatic setting, automatic power-off control etc. and has the self integration of hand function.
7, has identified and classified management function of insulating tools: through identification and classification of insulating tools to avoid wrong types of accidents, can carry on effective management of different voltage insulation tools;
